GD Grass Technical Specifications


Want to touch and feel our product?  Click Here! to order your samples now.

We provide sample packs ranging in price from $10-$25 depending on where you are in the USA or Canada.

SIZING

GD Grass™ 50-35*

Use: Residential driveway or fire access lanes where sporadic but heavy use is anticipated, access for campers and trailers.
Cell Size: 50 mm wide x 35 mm deep
Cell Wall Thickness: 2.0 mm
Sheet Size: 1.15 m  x .78 m (45.3" x 30.7") = 9.7 sq.ft.
Cell Colour: Green
Geotextile Fabric: No
Compressive Strength: 150 t/m2 (empty)
Suitable for vehicles: Yes

Small Projects:
Buy our CORE 50-35 Handypack (33 sq.ft.)


Larger Project:
Request a Quote or call us at 1.855.384.7336 (38green)

GD Grass™ 55-45*

Use: Residential, commercial applications, fire access lanes, access for campers and trailers.
Cell Size: 55 mm wide x 45 mm deep
Cell Wall Thickness: 3.0 mm
Sheet Size: 0.5 m  x 0.39 m (19.7" x 15.4" x 1.8") = 2.1 sq.ft.
Cell Colour: Green
Geotextile Fabric: No
Compressive Strength: >800 tons/m2 (Soil filled)
Suitable for vehicles: Yes
GD Markers: Yes

Request a Quote or call us at 1.855.384.7336 (38green)

CORE Grass 60-40 Cells: 60mm x 40mm deep Features built-in lateral drainage

GD Grass™ 60-40*

Use: Heavy duty vehicular traffic
Cell Size: 60 mm wide x 40 mm deep
Cell Wall Thickness: 2.5 mm
Sheet Size: 1.15 m x 1.0 m (45.3" x 39.4") = 12.4 sq.ft.
Cell Colour: Green
Geotextile Fabric: No
Compressive Strength: 200 t/m2 (empty)
Suitable for vehicles: Yes, Heavy Duty


The 60-40 is our new generation heavy duty panel, created for North American commercial parking lot applications (our trucks are just bigger!), rooftop (avoiding the need for drainage mats) and surfaces with a high water table. How? Using our BUILT-IN LATERAL DRAINAGE FEATURE.

Request a Quote or call us at 1.855.384.7336 (38green)

*These numbers represent the width and depth in millimetres of a each honeycomb-shaped cell


Click Here for a GD Grass Fact Sheet & Installation Guide.
Click Here for more GD Grass Resources.


We deliver Green Driveway products across North America and into Mexico.


Contact us for a project estimate or to purchase our materials for your personal or civic project.
